안핑 지옹캔 하드웨어 메쉬제 주식회사
원래 장소: | 안핑 중국 |
브랜드 이름: | JiongCan |
인증: | ISO9001 |
모델 번호: | jc-010 |
최소 주문 수량: | 100개 세트 |
---|---|
가격: | discussible |
포장 세부 사항: | BY 팔레트 |
배달 시간: | 7-10days |
지불 조건: | 전신환 |
공급 능력: | 10000 세트 |
상품 이름: | 체인 링크 펜스 | 원래 장소: | 허베이, 중국 |
---|---|---|---|
프레임 재료: | 금속 | 용법: | 정원 울짱, 스포츠 울타리, 농가 울타리 |
프레임 마감: | PVC는 코팅했습니다 | 메쉬: | 50x50mm |
특징: | 빠른 설치, 환경 친화적 | 색: | 검은 녹색 레드 브라운 |
샘플: | 자유롭게 하세요 | ||
하이 라이트: | 8Ft 다이아몬드 체인 링크 펜스,ISO9001 다이아몬드 체인 링크 펜스,8FT pvc 피복 다이아몬드 메쉬 |
Hot Dipped Galvanized 8FT Diamond Chain Link Fence Environmental Friendly
PVC Coated 8FT Green Metal Chain Link Wire Mesh Fence
Chain Link Fence Introduction:
Chain link fence is also called diamond wire mesh, produced with quality hot dipped galvanized wire or PVC coated wire.
The link fence can resist the corrosive and ultraviolet radiation very strongle. The fence obtain very strong powers to resist the concussion.
Chain Link Fence is normally used for protecting fencing and security fencing on playground, construction site, highway side, courtyard, public place, places of recreation and so on.
There're galvanized chain link fence and PVC coated chain link fence.
.
Common specifications:
Hole: 3mm-10cm
Silk warp: 2.0 mm-6.0 mm
Width: 1m-5m
Length: 3m-20m
Opening | 1" | 1.5" | 2" | 2-1/4" | 2-3/8" | 2-1/2" | 2-5/8" | 3" | 4" |
25mm | 40mm | 50mm | 57mm | 60mm | 64mm | 67mm | 75mm | 100mm | |
Wire diameter | 18# - 13# | 16# - 8 | 18#-7# | ||||||
1.2 - 2.4mm | 1.6mm - 4.2mm | 2.0mm-5.00mm | |||||||
Length of the roll | 0.50m - 100m(or more) | ||||||||
Width of the roll | 0.5m - 5.0m | ||||||||
Materials and specifications can be made according to customers'detailed requirements. |
PVC coated chain link fence | |||||
Opening | Wire Gauge | Width | Length | ||
Inch | mm | BWG | mm | m | m |
1"x1" | 25mmx25mm | BWG13-BWG12 | 2.2mm-3.0mm | 0.5-5m | 1.0m-50m |
1-1/2"x1-1/2" | 40mmx40mm | BWG13-BWG12 | 2.2mm-3.0mm | 0.5-5m | 1.0m-50m |
2"x2" | 50mmx50mm | BWG12-BWG9 | 2.2mm-3.6mm | 0.5-5m | 1.0m-50m |
2-3/8"x2-3/8" | 60mmx60mm | BWG13-BWG9 | 2.2mm-3.6mm | 0.5-5m | 1.0m-50m |
2-1/2"x2-1/2" | 63mmx63mm | BWG12-BWG9 | 2.6mm-3.5mm | 0.5-5m | 1.0m-50m |
3"x3" | 75mmx75mm | BWG12-BWG9 | 3.0mm-3.6mm | 0.5-5m | 1.0m-50m |
Remarks: 1. Special sizes are available upon request. 2. Packing: by pvc with both end. Customer's packing is available upon request. |
Galvanized chain link fence | |||
OPENING | WIRE GAUGE | WIDTH | LENGTH |
1'' | BWG11.12.13.14.15.16.17.18 | 0.5M-5M | 1.0M-50M |
1.5'' | BWG8,9,10,11,12,13,14,15,16 | 0.5M-5M | 1.0M-50M |
2'' | BWG8,9,10,11,12,13,14,15,16 | 0.5M-5M | 1.0M-50M |
2.25'' | BWG8,9,10,11,12,13,14,15,16 | 0.5M-5M | 1.0M-50M |
2.5 | BWG8,9,10,11,12,13,14,15,16 | 0.5M-5M | 1.0M-50M |
2.375'' | BWG8,9,10,11,12,13,14,15,16 | 0.5M-5M | 1.0M-50M |
3'' | BWG8,9,10,12,13,14,15,16 | 0.5M-5M | 1.0M-50M |
4'' | BWG8,9,10,12,13,14,15,16 | 0.5M-5M | 1.0M-50M |
Remarks:1.Special sizes are available upon request. 2.Packing:by PVC with both end or as customer's requirement. |
Excellent product technology meticulous work focus on quality guardrail products
processing and production after-sales worry free
Chain link fence is widely used as speed way, protection, safe guard on machinery, building wall, construction site, poultry fence, playing field, greening fence, waterways and residence safeguard, etc.
1.It's strong because of the steel framework, concrete footers, and interlocked wire.
2.It's versatile because it can accommodate grade changes, has different gauges/grades, can be vinyl coated.
3.It is durable because of the galvanized or vinyl coating processes in manufacturing for natural elements.
Delivery when will we have a professional inspectors to check the quality of the product is unqualified, such as qualified will paste the qualified product certificate, and then fixed by shipping packaging, packaging with the steel plate on the metal tray, and then fixed with metal packing tape, finally wrapped by plastic film packaging, general each pallet packing 1-2 tons of cargo, in order to convenient for unloading and storage after the arrival of the goods. The unqualified products will be recalled by our quality inspector.
After the customer orders, we will have professional technical personnel to contact with the customer, in order to meet the customer's technical inquiry and production schedule.
After the goods are shipped, we will have professional technical personnel to docking with customers, so that when the goods arrive, there will be unloading problems, storage and installation problems. Our technical personnel will reply online within 24 hours. If there is a problem, we will docking within 2 hours and help customers solve the problem within 5 hours.
